GENERAL
- Patented 3-CCD optical system provides full HD resolution images
- 4:2:2 processing
- Built-in Genlock
- 1080i / 720p / 480i multiscan
- Industry standard bayonet lens mount
JVC offers a wide range of lenses and accessories
- HDSDI output
Can also provide downconverted SDI output—live or playback.
- Patented Focus Assist function
- Extensive image customization modes (gamma, matrix, knee, detail, etc.)
ENG / FIELD PRODUCTION
- Compact Shoulder form factor
- Records to dual hot swappable SDHC memory cards
- Professional recording with selectable data rates up to 35Mbps
- 1920 x 1080 (1080p24/p25/p30, 1080i60/i50)
- 1280 x 720P (p60/p50/p30/p25/p24)
- SD recording capability (DV data format>
- Native file recording—world's fastest shoot-to-edit workflow.
- Native Final Cut Pro format
Edit immediately without conversion or transcoding
- .MP4 file format
Compatible with most popular editing systems
- Pool feed input (analog SD)
- Time code IN/OUT
- High resolution (1.22 million pixel) Liquid Crystal on Silicon (LCOS) viewfinder
- Large (4.3-inch) flip-out LCD monitor
- Pre Rec (retro cache up to 20 seconds) function prevents "missed shots"
- Variable frame rate recording (over crank, under crank)
- Built-in clip viewer and management system
- Uncompressed LPCM audio (2ch) recording
- Manual level controls with audio meter
- XLR inputs with phantom power
- Optional ASI output module
STUDIO OPTIONS
- Sturdy, sleek studio housing (sled)
- Large lens support
- High resolution 8.4-inch Studio Viewfinder
- 26-pin Multicore Module
- Fully featured multicore CCU
- Local Remote Panel (shader)
- Fiber Remote Module
- Wide range of lenses and lens accessories
